Luxury Prefabricated Villa High-End Light Steel Mansion House 4 Bedrooms, 2 Bathrooms Customizable Design
Kilburne House
2 Living
4 bedrooms 3 bathrooms 2 car spaces 282.04m²
4 Bedroom 2 Living 1 Kitchen 3 Bathroom 2 Garage Area:282.04m²
Boasting four bedrooms, two living areas, a well-appointed kitchen, three bathrooms, and two garages, Kilburne House provides ample space for you and your loved ones. With a total area of 282.04 square meters, it strikes the perfect balance between practicality and aesthetics. The model DPBL-24-09 showcases a unique design, measuring 13790×23870 millimeters. Its meticulously crafted layout ensures seamless flow between different areas of the house.
Floor plan
Kilburne House, a splendid creation from DEEPBLUE SMARTHOUSE, stands as a symbol of comfort and elegance.
This charming abode features four bedrooms, two living areas, one kitchen, three bathrooms, and two garages, offering a generous living space for you and your loved ones. With a total area of 282.04 square meters, it provides a perfect balance of functionality and style. The model DPBL-24-09 showcases a unique design with dimensions of 13790×23870mm. The carefully crafted layout ensures a seamless flow between different areas of the house.
|
NO:
|
DPBL-24-09
|
|
Hosue Name:
|
Kilburne House
|
|
House Width:
|
13.8m
|
|
House Length:
|
23.9m
|
|
Area:
|
282.02m²
|
DEEPBLUE SMARTHOUSE takes great care in providing all the materials for Kilburne House. The light steel frame provides a solid foundation, while the high-quality floors, beautiful walls, well-appointed kitchen, inviting living areas, and luxurious bathrooms are all designed to meet the highest standards. Their expert team combines innovation and craftsmanship to create a home that is not only aesthetically pleasing but also highly functional.
Specifications
1. Structure: 0.75mm/0.95mm/1.15mm light gauge steel
2. Foundation: you need to prepare by yourself. Concrete foundation, or other foundation
3. Roof: Colorbond sheet, asphalt shingle, ceramic tile, stone-metal sheet
4. External wall: EPS sandwich panel, ALC panel, metal PU sandwich panel, pre-painted fiber cement board, CFC board, WPC board
5. Internal wall: Gypsum board, MGO board, integrated wall panel, etc.
6. Ceiling: Gypsum board, MGO board, integrated wall panel, etc.
7. Underneath for floor: CFC sheet, OSB board
8. Insulation: R2.5/3.5/4/5 glass wool, rock wool
9. Flooring: ceramic tile, laminated flooring, PVC flooring, wooden flooring
10: Window: double/single glass Alu. window
11: Door: normal security door, plywood door, alu. door, WPC door, wooden door
12: Electrical and plumbing system
14: Kitchen: wall cabinet, top cabinet, sink, faucet, benchtop
15: Bathroom: washbasin, toilet, shower
Why Choose Light Gauge Steel Structure?
1)Lifetime for structure: 100 years.[0.75~1.2mm , Z275galvanized steel profile, strength:550Mpa ]
2)Earthquake resistance: mix more than 8 grades.
3)Wind resistance:max 60m/s.
4)Fire resistance:all the materials used can be fire resistance.
5)Snow resistance:max 2.9KN/m²as required
6)Heat insulation:100 mm in thickness can match 1 m thickness of brick wall.
7)High acoustic insulation:60db of exterior wall 40db of interior wall
8)Insect prevention: Free from the damages by insects, such as white ants
9)Ventilation:a combination of natural ventilation or air supply keep the indoor air fresh and clean
10)Packing and delivery: 140SQM/ 40'HQ container for structure only and 90SQM/ 40'HQ container for structure with decorate materials.
11)Installation:the average is one worker one day install one SQM.
12)Installation guide:dispatch engineer to guide on site.
Design code:
(1)AISI S100 North American Specification for the Design of Cold Formed Steel Structural Members published by the American Iron and Steel Institute (AISI) in the United States.
(2)AS/NZS 4600 Australian/New Zealand Standard-Cold-formed steel structures jointly published by Standards Australia and Standards New Zealand.
(3)BS 5950-5 Structural use of steelwork in building-Part 5. Code of practice for design of cold formed thin gauge sections published by BSI in the UK.
(4)ENV1993-1-3 means Eurocode 3: Design of steel structures; Part 1.3: General rules, Supplementary rules for cold-formed thin gauge members.
Company Information
Founded in 2009, Deepblue Smarthouse is a high-tech enterprise integrating design, manufacturing, sales, logistics, and installation into a seamless one-stop service. Committed to providing safe, comfortable, and affordable homes, we have successfully delivered large-scale overseas real estate and resort projects, with products exported to 60+ countries and NGOs. Backed by 81 patents and numerous design awards, we have built over 10,000 homes worldwide. Powered by advanced equipment, a professional team, and a culture of continuous training, we remain steadfast in our core promise: putting customers first.
The DeepBlue Smarthouse world is one with advanced production equipment, managed by outstanding professionals, within a sound training environment. Together with our excellent corporate atmosphere we provide you with first-for our customers, that's our commitment to you.
Packaging & Shipping
Well packed export quality package ,shipped by 40hq.
