Product Details:
Place of Origin: NINGBO,CHINA
Brand Name: DEEPBLUE
Certification: AS/NZS,UL,AISI,
Model Number: BOLOGNA
Payment & Shipping Terms:
Minimum Order Quantity: 3 SETs
Price: 300-600USD/SQM
Packaging Details: Bare bundle / 40HQ
Delivery Time: 30-45days
Payment Terms: T/T, Western Union, L/C
Supply Ability: 12000houses/year
Contact Now
Detailed Product Description
Exterior Door: Aluminium Sliding Doors Lighting: C.E , AS/NZS , UL Standard Light Or Others
Ceiling: PVC Ceiling Panel Flooring: Wooden Or Bamboo Flooring
Insulation: High Performance Glass Wool Interior Lining: Fiber Cement Board
High Light:

booths garden studios

,

contemporary garden studios

,

PVC Ceiling Panel Prefab Loft House

Kit Form Steel Frame Prefab Modular Homes Prefab Loft House PVC Ceiling Panel



Quick Detail:


Name holiday home Application Some house for holiday living
Color Yellow, white, etc depend on customer’s request Feature 1.U.K engineer approved;
2.Earthquake, cyclone and fireproof;
3.100years life;
4.Green, Energy save
Material light steel frame and other parts material Certificate

CE,ISO,SAA,ETC





Kit Form Steel Frame Prefab Modular Homes Prefab Loft House PVC Ceiling Panel 0

Kit Form Steel Frame Prefab Modular Homes Prefab Loft House PVC Ceiling Panel 1


Applications:

Hotel, House, Office, etc.



Kit Form Steel Frame Prefab Modular Homes Prefab Loft House PVC Ceiling Panel 2

Product Description

DeepBlue earthquake proof prefabricated bungalow is based on a light gauge steel frame system with high-performance finishing materials. The whole house can be assembled within a couple of hours by 4workers.
the materials are the following:
1. Main structure: 89mm light gauge steel framing system based on AS/NZS 4600 standard.
the structure can be design to resist 50m/s wind and 9degree earthquake.
2. Roof structure: 89mm light gauge steel truss system.
3. Chassis: 89mm light gauge steel flooring chassis
4. flooring: 18mm fiber cement board with vapor barrier and bamboo flooring or wooden flooring, PVC carpet, etc.
5.Wall cladding: 16mm PU insulated steel sandwich panel with beautiful decoration
6. interior lining: 9mm fiber cement board,water-proof,termite-proof, security and healthy
7. ceiling: 8mm PVC ceiling panel
8. insulation: 89mm glass wool insulation with good soundproof performance.
9.windows: PVC sliding windows
10.exterior door: high-quality aluminum sliding windows
11.interior door: painted wood door
12.bathroom: shower, washbasin, toilet included
13. roofing: corrugated steel roofing with a gutter system
14. veranda deck: W.P.C veranda flooring.



Specifications

Home accents holiday :

ISO standard light gauge steel for main structure.one or two also three floors available. fireproof, heat insulation, wind, and earthquake resistance.green, energy saving. economically.


Why Choose Light Gauge Steel Structure?

1)Lifetime for structure: 100 years.
2)Earthquake resistance: mix more than 8 grades.
3)Wind resistance:max 60m/s.
4)Fire resistance: all the materials used can be fire resistance.
5)Snow resistance: max 2.9KN/m²as required
6)Heat insulation:100 mm in thickness can match 1 m thickness of the brick wall.
7)High acoustic insulation:60db of exterior wall 40db of interior wall
8)Insect prevention: Free from the damages by insects, such as white ants
9)Ventilation: a combination of natural ventilation or air supply keep the indoor air fresh and clean
10)Packing and delivery: 140SQM/ 40'HQ container for structure only and 90SQM/ 40'HQ container for structure with decorating materials.
11)Installation: the average is one worker one day install one SQM.
12)Installation guide: dispatch engineer to guide on site.


Design code:

(1)AISI S100 North American Specification for the Design of Cold-Formed Steel Structural Members published by the American Iron and Steel Institute (AISI) in the United States.
(2)AS/NZS 4600 Australian/New Zealand Standard-Cold-formed steel structures jointly published by Standards Australia and Standards New Zealand.
(3)BS 5950-5 Structural use of steelwork in building-Part 5. Code of practice for the design of cold-formed thin gauge sections published by BSI in the UK.
(4)ENV1993-1-3 means Eurocode 3: Design of steel structures; Part 1.3: General rules, Supplementary rules for cold-formed thin gauge members.





Service Process



customized design service & personalized option



If You Need: prefabricated kit home; prefab kit home. steel structure homes.steel frame house



Only Need You To Provide Us: house area, how many floors and bedrooms, luxury or normally, or low-cost configuration.



We Can Provide You: villa; bungalow; low-cost house; granny flat; apartment etc.many style house.



Kit Form Steel Frame Prefab Modular Homes Prefab Loft House PVC Ceiling Panel 3

DeepBlue Smarthouse Company information


Since founding the company in 2009, we have prided ourselves on providing cost-effective custom and modular homes, apartments and commercial buildings for people around the world. So far, we have built more than 5,000 homes and won many awards for design and construction. Today, we build, sell, finance, and lease our buildings from China to the world.

We have a new large processing center and modern production workshop, in order to ensure the accuracy of production products, in strict accordance with technical specifications and quality control to produce high-quality products.



.jpg

Kit Form Steel Frame Prefab Modular Homes Prefab Loft House PVC Ceiling Panel 5


Packaging & Shipping

Granny Flat's packing: well-packed export quality package, shipped by 40hq.

Kit Form Steel Frame Prefab Modular Homes Prefab Loft House PVC Ceiling Panel 6



Your first choice, Deepblue Prefabricated house in China.
