Fast Assemble Light Steel Structure Prefabricated Villa In AU/EU/US Standard With Two Floor

Fast Assemble Light Steel Structure Prefabricated Villa In AU/EU/US Standard With Two Floor

  • Fast Assemble Light Steel Structure Prefabricated Villa In AU/EU/US Standard With Two Floor
  • Fast Assemble Light Steel Structure Prefabricated Villa In AU/EU/US Standard With Two Floor
Fast Assemble Light Steel Structure Prefabricated Villa In AU/EU/US Standard With Two Floor
Product Details:
Place of Origin: NINGBO,CHINA
Brand Name: DEEPBLUE
Certification: AS/NZS,UL,AISI,
Model Number: DPBL-100#
Payment & Shipping Terms:
Minimum Order Quantity: 2 SETS
Price: 200-500 USD/SQM
Packaging Details: Bare bundle / 40HQ
Delivery Time: 30-45 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 12000 houses/year
Contact Now
Detailed Product Description
Insulation: Glass Wool/EPS/XPS/PU Sandwich Panel Ceiling Material: MGOboard/ Gypsum Board+others
Floor: Laminate/wooden/tile Door: Metal Security Door/Pvc Sliding Door
Roofing: EPS Sandwich Panel/steel Roofing/asphalt Other Fitting: Toilet, Washbasin,shower ,kitchen,etc
High Light:

pre manufactured homes

,

steel frame houses

Quickly Assemble Prefabricated Villa, Two Floors Prefab Steel House With Long Lifetime



Fast Assemble Light Steel Structure Prefabricated Villa In AU/EU/US Standard With Two Floor 0 4 bedrooms     Fast Assemble Light Steel Structure Prefabricated Villa In AU/EU/US Standard With Two Floor 13 bathrooms   Fast Assemble Light Steel Structure Prefabricated Villa In AU/EU/US Standard With Two Floor 22 livingrooms   Fast Assemble Light Steel Structure Prefabricated Villa In AU/EU/US Standard With Two Floor 3 170 m²



Fast Assemble Light Steel Structure Prefabricated Villa In AU/EU/US Standard With Two Floor 4



The two-floor villa with pure light steel structure is more environmentally friendly than ordinary concrete houses, reducing dust pollution in construction projects. The use of glass doors and windows makes the daylighting better, and the sound insulation and fire resistance of walls are better than ordinary houses.

  • Simple and modern house design
  • Experience the elegant and novel design concept on this basis
  • Based on the most advanced Light Gauge Steel Frame Technology

Floor plan

  • On the first floor, there is a living room, a dining area, an open kitchen, a bathroom, and a bedroom with a study room.
  • Four bedrooms on the second floor, one of which has a separate bathroom, a public bathroom, and a large open balcony
  • The large balcony can be decorated with flowers, which can dry clothes and quilts
  • The overall design meets the needs of daily families, and also more in line with the accommodation industry.

    Fast Assemble Light Steel Structure Prefabricated Villa In AU/EU/US Standard With Two Floor 5





Quick Detail:



Name

prefabricated villa

Application

Villa for living

Color

According to the customer's requirements



Feature

1.quickly to assemble on-site;

2.good earthquake proof;

3.green and energy save;

material light steel and other parts material

Certificate

CE,ISO,SAA,ETC



Main structure: Light Gauge Steel

Wall material: ALC panel/fiber cement cladding+MGO board/gypsum board

Lifetime: 100 years for structure



Fast Assemble Light Steel Structure Prefabricated Villa In AU/EU/US Standard With Two Floor 6



Applications:



House, Office, Villa, etc.



Product Description:



DeepBlue steel structural prefab villa is based on a light gauge steel frame system with high-performance finishing materials. The whole house can be assembled within a couple of hours by 4workers. the materials are the following:

1. Main structure: 89mm light gauge steel framing system based on AS/NZS 4600 standard.  the structure can be design to resist 50m/s wind and 9degree earthquake.

2. Roof structure: 89mm light gauge steel truss system.

3. Chassis: 89mm light gauge steel flooring chassis

4. flooring: 18mm fiber cement board with vapor barrier and bamboo flooring or wooden flooring, PVC carpet, etc.

5.Wall cladding: 16mm PU insulated steel sandwich panel with beautiful decoration

6. interior lining: 9m fiber cement board,water-proof,termite-proof, security and healthy

7. ceiling: 8mm PVC ceiling panel

8. insulation: 89mm glass wool insulation with good soundproof performance.

9.windows: PVC sliding windows

10.exterior door: high-quality aluminum sliding windows

11.interior door: painted wood door

12.bathroom: shower, washbasin, toilet included

13. roofing: corrugated steel roofing with a gutter system

14. veranda deck: W.P.C veranda flooring.

ISO standard light gauge steel for the main structure. fireproof, heat insulation, wind, and earthquake resistance.green, energy saving. also economically.



Why Choose Light Gauge Steel Structure?



1)Lifetime for structure: 100 years.[0.75~1.2mm , Z275galvanized steel profile, strength:550Mpa ]

2)Earthquake resistance: mix more than 8 grades.

3)Wind resistance:max 60m/s.

4)Fire resistance: all the materials used can be fire resistance.

5)Snow resistance: max 2.9KN/m²as required

6)Heat insulation:100 mm in thickness can match 1 m thickness of the brick wall.

7)High acoustic insulation:60db of exterior wall 40db of interior wall

8)Insect prevention: Free from the damages by insects, such as white ants

9)Ventilation: a combination of natural ventilation or air supply keep the indoor air fresh and clean

10)Packing and delivery: 140SQM/ 40'HQ container for structure only and 90SQM/ 40'HQ container for structure with decorating materials.

11)Installation: the average is one worker one day install one SQM.

12)Installation guide: dispatch engineer to guide on site.



Fast Assemble Light Steel Structure Prefabricated Villa In AU/EU/US Standard With Two Floor 7



Design code:



(1)AISI S100 North American Specification for the Design of Cold-Formed Steel Structural Members published by the American Iron and Steel Institute (AISI) in the United States.

(2)AS/NZS 4600 Australian/New Zealand Standard-Cold-formed steel structures jointly published by Standards Australia and Standards New Zealand.

(3)BS 5950-5 Structural use of steelwork in building-Part 5. Code of practice for the design of cold-formed thin gauge sections published by BSI in the UK.

(4)ENV1993-1-3 means Eurocode 3: Design of steel structures; Part 1.3: General rules, Supplementary rules for cold-formed thin gauge members.



office&factory:

Deepblue Smarthouse was founded in 2009, a high-tech enterprise which integrated the ability of design, production, sales, transportation, installation, and other services as a whole. We always committed to providing every family with a comfortable, safe, and affordable home, and also can provide a one-stop service for customers in this field. At present, we have completed many overseas real estate projects, large resort projects, and so on. Our products have been exported to more than 60 countries and NGOs. With 59 patents of invention and utility models, we have built more than 5,000 houses and won many awards in design and architecture.



Fast Assemble Light Steel Structure Prefabricated Villa In AU/EU/US Standard With Two Floor 8



If You Need: prefabricated kit home; prefab kit home. steel structure homes.steel frame house

Only Need You To Provide Us: house area, how many floors and bedrooms, luxury or normally, or low-cost configuration.

We Can Provide You: villa; bungalow; low-cost house; granny flat; apartment etc.many buildings.
