Beautiful Bali style Cyclone proof Moistureproof Prefab house Home Beach wooden Bungalows in Maldives

Place of Origin NINGBO,CHINA
Brand Name DEEPBLUE
Certification AS/NZS,UL,AISI,
Model Number DP-B-10
Minimum Order Quantity 2 SET
Price Negotiation
Packaging Details Bare bundle / 40HQ
Delivery Time 30-45 days
Payment Terms L/C, T/T, Western Union
Supply Ability 12000houses/year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Steel Frame AZ150 G550 Light Steel 0.75mm Exterior Wall Ext. Wall Cladding
Interior Wall Panel (dry Area) Integrated Wall Panel/gypsum Board Skirting 50mm High PVC Skirting/Plywood Skirting
Ceiling Panel Integrated Wall Panel/gypsum Board Soffit 8mm PVC Panel/6mm CFC Sheet
High Light

luxury beach bungalows

,

garden beach bungalows

,

luxury beach bungalows

Leave a Message
Product Description

Beautiful Bali style Cyclone proof Moistureproof Prefab house Home Beach wooden Bungalows in Maldives



DEEPBLUE' s Light Gauge Steel House, use light gauge steel as structure, which is a new material with the characteristics of light weight, high strength; Can use all kinds of new building plate material to decorate it, some are good insulation and fire resistance materials for roof, for wall and for floor. Our system make the whole house good earthquake proof, fast and easy to assemble on site, green, and energy save, comfortable for living.





Quick Detail:



Name

Wooden bungalow

Application

Wooden bungalow for holiday living, resort, tourist

Color

Yellow,white,etc depend on customer’s request

Feature

1.quickly to assemble on site

2.good earthquake proof

3.green,energy save

4.design for customers

Material

 light steel and other parts material

Certificate

CE,ISO,SAA,ETC





Description:



1. Chasis: steel chasis

2. Floor: CFC sheet, with vinyl flooring, wooden flooring, floor tiles, laminated flooring, etc.

3. Main structure: Light steel frame

4. External wall: WPC cladding, metal PU sandwich panel, fiber cement, pre-painted fiber cement board, wooden cladding, etc.

5. Internal wall: Gypsum board, intergrated wall panel, wooden cladding, MGO board, etc.

6. Ceiling: Gypsum board, intergrated wall panel, wooden cladding, MGO board, etc.

7. Roof: colorbond roof sheet, asphalt roof shingle, etc.

8. Windows: Aluminium double glass window, PVC double glass winodw, single glass window, etc.

9. Door: MDF door, WPC door, wooden door, etc.

10. Kitchen: cabinet, sink, faucet, countertop, etc.

11. Bathroom: Toilet, shower, tap, vanity, washbasin, etc.







Applications:



toilet,washbasin,shower,kitchen etc.





Specifications



light steel framing bali prefab wooden houses:

ISO standard light gauge steel for main structure.one or two also three floors available.fireproof,heat insulation,wind and earthquake resistance.green,energy save. economically.



 Beautiful Bali style Cyclone proof Moistureproof Prefab house Home Beach wooden Bungalows in Maldives 0Beautiful Bali style Cyclone proof Moistureproof Prefab house Home Beach wooden Bungalows in Maldives 1Beautiful Bali style Cyclone proof Moistureproof Prefab house Home Beach wooden Bungalows in Maldives 2





Design code:



(1)AISI S100 North American Specification for the Design of Cold Formed Steel Structural Members published by the American Iron and Steel Institute (AISI) in the United States.

(2)AS/NZS 4600 Australian/New Zealand Standard-Cold-formed steel structures jointly published by Standards Australia and Standards New Zealand.

(3)BS 5950-5 Structural use of steelwork in building-Part 5. Code of practice for design of cold formed thin gauge sections published by BSI in the UK.

(4)ENV1993-1-3 means Eurocode 3: Design of steel structures; Part 1.3: General rules, Supplementary rules for cold-formed thin gauge members.





Why Choose Light Gauge Steel Structure?



1. Anti-seismic: Most villas use slope roofing with truss system. The roofing system will be very strong after the truss was sealed with panels, it can against 8-degree earthquake, and has high strength of loading capability.

2. Good Performance for against wind: light weight, high strength, good integrity, not easy to deform, all these advantages make light gauge steel building good performance for against wind. It can resist the cyclone at the speed of 60m/s, thus protecting the building and people’s life.

3. Durability: light gauge steel building uses cold-formed galvanized steel, thus avoiding rust in the course of construction and use, and makes the life span of the structure 100 years.

4. Heat Preservation Performance: Heat preservation: we use glass wool as insulation and effectively avoid the phenomenon of cold bridge of the wall body. The heat preservation effect of 100mm glass wool is equivalent to 1m-thick brick wall.

5. Fire Resistance: As the experiment data shows, use good fire proof decorate material, light steel system can resist fire for four hours and can effectively slow down the fire spreading.

6. Sound-proof Performance: Sound-proof performance is an important item for evaluating the accommodation. Light steel system adopt hollow glass for windows, which can soundproof for 40 db. The light steel wall system can soundproof for 60 db.

7. Healthiness: dry construction, minimum waste to the environment, and 100% recyclable of the materials, all these advantages are conform to the consciousness of environmental protection. What’s more, the materials we use are all green materials, which are good for people’s health.

8. Comfort: Light steel wall system adopts highly efficient energy-saving system with respiration function to adjust the humidity of the room; with ventilation function in the roof, ensuring the ventilation and hot scattering of the room, thus make the room more comfortable.

9. Termite resistant: The light steel buildings can completely resist termite invasion, thus extending the life span of the house and decrease the repair cost.

10. Fast to assemble: Dry construction and without the influence of season. A 300sqm-building only need 10 workers for 30 days from the foundation to everything finished.

11. Environmental friendly: Materials are 100% recyclable, and no pollute to the environment.

12. Energy-Saving: Efficient and energy-saving wall has good performance on heat keeping and sound proofing, and can achieve the energy-saving standard for 85%.



Material Configuation:



No.

Item

Materials

Luxury house

No.

Item

Materials

Luxury house

1

Foundation

Fixing to Foundation

chemical bolt

6

Roof system

roofing

ceramic/asphalt shingle

cushion tape between frame and foundation

asphalt tape

water-proof layer

heavy duty asphalt layer

2

House Structure System

Main sturcture for house

1.15mm thk *89mm wide Steel frame

strength board

15mm OSB board

Floor Joist   (if multi stories)

1.15mm steel joist

Insulation/batt

heavy duty glass wool

Connection

self-drilling scress

eaves board

12mm MgO board

3

Exterior Wall

Ext. wall Cladding

50MM ALC PANEL or PU sandwich panel

downpipe system

PVC downpipe system

Reinforce layer

12mm OSB board

7

Kitchen and bathroom

Kitchen cabinet

high quality cabinet

Vapor barrier

DUPONT Vapor barrier sheet

wall cabinet

high quality wall cabinet

Insulation/batt

heavy duty glass wool

counter top

stone counter top

inter of ext .wall

double 12mm plaster board

Sink

high quality stainless sink with faucet

4

Interior Partition wall

siding

double 12mm plaster board

toilet

high quality toilet

cornering

high quality plaster cornering

bathtub

high quality bathtub

Skirting

solid wood and tile

shower

high quality shower

5

Floor System

sub floor for ground floor (Wet area )

NULL

8

Doors and windows, plumbing

Exterior door

security door

Sub floor for   other floor ( Wet area )

20mm fiber cement board

windows

double glass Alum. Windows

flooring for gound floor (dry area)

wooden flooring

interior door

high quality plywood door

flooring for gound floor ( wet area)

high quality ceramic tile

hot&cold water pipe

hig quality PPR PIPE

Flooring for other floor (wet area)

high quality ceramic tile

Downpipe

high quanlity PVC downpipe

Flooring for other floor dry area

wooden flooring

9

Electrical system and multi media

telphone cable

included

Insulation

glass wool

TV. CABLE

included

Ceiling for dry area

12mm plaster board

internet cable

included

ceiling for wet area

PVC ceiling

electrical cables

included

stairs (If have)

steel stairs with armrest

lighting

ceiling light

notice:

distribution box

Included

1

EX.W mean EX.works, pls find explaination from wikipedia

switch

Included

2

This price does not include foundation ,cement works and any other cost.

11

Others

INSTALLATION FEE

Optional

3

This price does not include design fee.

SUPERVISOR

Optional

4

This price does not include any furnitures and others.

5

This price is only for listed materials

6

All electrical is based on Chinese standard equipments.

7

The total widnows area is no more than 15% of building area. The ceiling height is calculated 2.5m.

8

Final price need to be confirmed based on final drawings and order-confirm-letter.

9

If you have any questions, pls contact DEEPBLUE.
