|Place of Origin:||China|
|Minimum Order Quantity:||2 SETS|
|Packaging Details:||Bare bundle / 40HQ|
|Delivery Time:||30-45 days|
|Payment Terms:||L/C, T/T, Western Union|
|Supply Ability:||12000 houses/year|
|Use:||Villa,House||Type:||2 Floors,Light Steel Structure Frame|
|Size:||Customized,100-300 Square Meters||Frame Material:||0.75 Mm/0.95 Mm/1.15 Mm Steel Frame With AZ150 Zinc Coating|
|External Wall:||100 Or 50 Mm ALC Panel/WPC Board/fibre Cement,etc||Insulation:||Glass Wool/EPS/XPS/PU Sandwich Panel|
|Ceiling Material:||MGO Board/ Gypsum Board+others||Floor:||Laminate/wooden/tile|
|Door:||Metal Security Door/PVC Sliding Door||Roofing:||EPS Sandwich Panel/steel Roofing/asphalt|
|Other Fitting:||Toilet, Washbasin,shower ,kitchen,etc|
Two Story Modular Prefab Villa,
Light Steel Structure Prefab Villa
Two Story Steel Structure House Modular Light Steel Structure Prefab Villa
|Name||prefabricated villa||Application||Villa for living|
1.quickly to assemble on-site;
2.good earthquake proof;
3.green and energy save;
|Material||light steel and other parts material||Certificate||
Main structure: Light Gauge Steel
Wall material: ALC panel/fiber cement cladding+MGO board/gypsum board
Insulation material: Insulation material
Ceiling material: MGO board/gypsum board
Floor/foundation material: laminate flooring/wooden/PVC carpet
Door: steel security door/WPC or plywood door
Window: aluminum alloy/PVC
Roofing: EPS sandwich panel/steel roofing/asphalt shingle
Other fittings: toilet, washbasin, shower, kitchen, etc.
Lifetime: more than 70 years
House, Office, Villa, etc.
DeepBlue steel structural prefab villa is based on a light gauge steel frame system with high-performance finishing materials. The whole house can be assembled within a couple of hours by 4workers. the materials are the following:
1. Main structure: 89mm light gauge steel framing system based on AS/NZS 4600 standard. the structure can be design to resist 50m/s wind and 9degree earthquake.
2. Roof structure: 89mm light gauge steel truss system.
3. Chassis: 89mm light gauge steel flooring chassis
4. flooring: 18mm fiber cement board with vapor barrier and bamboo flooring or wooden flooring, PVC carpet, etc.
5.Wall cladding: 16mm PU insulated steel sandwich panel with beautiful decoration
6. interior lining: 9mm fiber cement board,water-proof,termite-proof, security and healthy
7. ceiling: 8mm PVC ceiling panel
8. insulation: 89mm glass wool insulation with good soundproof performance.
9.windows: PVC sliding windows
10.exterior door: high-quality aluminum sliding windows
11.interior door: painted wood door
12.bathroom: shower, washbasin, toilet included
13. roofing: corrugated steel roofing with the gutter system
14. veranda deck: W.P.C veranda flooring.
ISO standard light gauge steel for the main structure. fireproof, heat insulation, wind, and earthquake resistance.green, energy saving. also economically.
Advantages of light steel structure
1.Construction period: Short construction period；construction is less affected by weather conditions.
2.Construction difficulty: Prefabricated construction parts, low construction difficulty
3.Environmental performance: Dry operation, basically no pollution to the environment
4.Maintainance: Less maintenance and low maintenance cost
5.Earthquake resistance: mix more than 8 grades.
6.Wind resistance:max 60m/s.
7.Fire resistance: all the materials used can be fire resistance.
8.Snow resistance: max 2.9KN/m²as required
9. Heat insulation:100 mm in thickness can match 1 m thickness of the brick wall.
10.High acoustic insulation:60db of exterior wall 40db of interior wall
11.Insect prevention: Free from the damages by insects, such as white ants
12.Ventilation: a combination of natural ventilation or air supply keep the indoor air fresh and clean
Since Yinhua Chen founded the company in 2009, we have been proud to provide affordable manufactured and modular homes, apartments, commercial buildings, military barracks, and college dormitories to people all across the world. From humble beginnings, we have built more than 5000 homes and won multiple awards for both design and construction. Today we build, sell, finance, lease, and ensure our building from China to the world
(1) With over 10 years of experience in the Prefab housing Business;
(2)Exporting prefab houses to more than 60 countries and NGO, including USA, Australia, France, Africa, South America, United Nation;
(3)Owner of 59 patents;
(4)including our revolutionary Unique folding design patent;
(5)Supply both Luxury house and social housing;
(6)Excellent understanding in Developer/Builder relationship requirements
(7)Expert at low-cost housing solutions for government
If You Need: prefabricated kit home; prefab kit home. steel structure homes.steel frame house, light steel structure, Tiny House on wheels, social house, apartment building, commercial building...
Only Need You To Provide Us: house area, how many floors and bedrooms, luxury or normally, or low-cost configuration.
We Can Provide You: villa; bungalow; low-cost house; granny flat; apartment etc.many style house.
