Office Prefab Bungalow Homes Light Gauge Steel Frame Material Energy Saving

Office Prefab Bungalow Homes Light Gauge Steel Frame Material Energy Saving

Alandra House

The Alandra is designed for a beach resort, located in trees, you can be closer to nature and enjoy your holiday time here. It will give you a bright airy feeling, with the big windows and balcony. The wooden like external wall makes the whole bungalow better integrate into a beautiful environment.

l Chill out in the spacious master bedroom

• Open living area that connects to the alfresco lets in more fresh air and sunlight
• Big windows and balcony make you feel like in nature


Quick Detail:




Description:

Main structure: Light Gauge Steel
Wall material: ALC panel/fiber cement cladding+MGO board/gypsum board
Insulation material: Insulation material
Ceiling material: MGO board/gypsum board
Floor/foundation material: laminate flooring/wooden/PVC carpet
Door: steel security door/WPC or plywood door
Window: aluminum alloy/PVC
Roofing: EPS sandwich panel/steel roofing/asphalt shingle
Other fittings: toilet, washbasin, shower, kitchen, etc.
Lifetime: 100 years for structure

Applications:

House, Office, Villa, etc.

Why choose a light steel frame house for the resort?
1. Fast and easy to install, you can get money back quickly, and cost less in construction.
2. Termite resistant.
3. Fire-resistant, the main steel structure can resist 4 hours of the fire.
4. Earthquake resistant, our steel structure can resist a 9-degree earthquake.
5. Lightweight, each panel can easily carry by 2-3 people, no need crane.
6. Cyclone resistant, our steel homes can resist 78m/s wind.
7. Flexible design, you can design in any style and shape
8. Durable, the lifespan of the main structure can be 100 years
9. Comfortable
10. Eco-friendly

ISO standard light gauge steel for the main structure. fireproof, heat insulation, wind, and earthquake resistance.green, energy saving. also economically.



Why Choose Light Gauge Steel Structure?

1) Lifetime for structure: 100 years.[0.75~1.2mm , Z275galvanized steel profile, strength:550Mpa ]
2) Earthquake resistance: mix more than 8 grades.
3) Wind resistance:max 60m/s.
4) Fire resistance: all the materials used can be fire resistance.
5) Snow resistance: max 2.9KN/m²as required
6) Heat insulation:100 mm in thickness can match 1 m thickness of the brick wall.
7) High acoustic insulation:60db of exterior wall 40db of interior wall
8) Insect prevention: Free from the damages by insects, such as white ants
9) Ventilation: a combination of natural ventilation or air supply keep the indoor air fresh and clean
10) Packing and delivery: 140SQM/ 40'HQ container for structure only and 90SQM/ 40'HQ container for structure with decorating materials.
11) Installation: the average is one worker one day install one SQM.
12) Installation guide: dispatch engineer to guide on site.


Production in DeepBlue factory:



Design code:

(1) AISI S100 North American Specification for the Design of Cold-Formed Steel Structural Members published by the American Iron and Steel Institute (AISI) in the United States.

(2) AS/NZS 4600 Australian/New Zealand Standard-Cold-formed steel structures jointly published by Standards Australia and Standards New Zealand.

(3) BS 5950-5 Structural use of steelwork in building-Part 5. Code of practice for the design of cold-formed thin gauge sections published by BSI in the UK.

(4) ENV1993-1-3 means Eurocode 3: Design of steel structures; Part 1.3: General rules, Supplementary rules for cold-formed thin gauge members.


Resistant to various weather conditions, due to its light gauge steel framing system, DeepBlue Mobile Homes can resist winds up to 50m/s, 50cm snow loads as well withstand earthquakes due to its special steel structure technology.
The DeepBlue Mobile Houses manufacturing technology is truly a mature product characterized by flexibility and innovative design and solution.


If You Need: prefabricated kit home; prefab kit home. steel structure homes.steel frame house

Only Need You To Provide Us: house area, how many floors and bedrooms, luxury or normally, or low-cost configuration.

We Can Provide You: villa; bungalow; low-cost house; granny flat; apartment etc.many buildings.
