Light Steel Frame Prefab Eco Modular Tiny Trailer Home Modular Prefabricated Homes

Place of Origin NINGBO,CHINA
Brand Name DEEPBLUE
Certification CE,ISO
Model Number ODESSY
Minimum Order Quantity 1 unit
Price USD22000~28000/unit
Packaging Details 40`FR
Delivery Time 60~70days
Payment Terms T/T, Western Union
Supply Ability 10 units/60 days
Product Details
Structure Light Steel Frame Roofing Colorbond
Exterior Wall PU Sandwich Metal Panel Interior Wall WPC Panel
Flooring Laminated Flooring Color Optional
High Light

pre manufactured homes

,

steel frame houses

Leave a Message
Product Description

Light Steel Frame Prefab Eco Modular Tiny Trailer Home Modular Prefabricated Homes





No. Structure Material
1 trailer 2 axes steel trailer
2 mainframe light steel frame
3 roof color bond roofing
4 external wall matel PU sandwich panel
5 internal wall integrated panel
6 floor laminated flooring
7 kitchen and bathroom standard
8 window and door double glass window, standard door
9 electrical and plumbing system standard



Design Code:

1) AISI S100 North American Specification for the Design of Cold-Formed Steel Structural Members published by the American Iron and Steel Institute (AISI) in the United States.
2) AS/NZS 4600 Australian/New Zealand Standard-Cold-formed steel structures jointly published by Standards Australia and Standards New Zealand.
3) BS 5950-5 Structural use of steelwork in building-Part 5. Code of practice for the design of cold-formed thin gauge sections published by BSI in the UK.
4) ENV1993-1-3 means Euro code 3: Design of steel structures; Part 1.3: General rules, Supplementary rules for cold-formed thin gauge members.





Light Steel Frame Prefab Eco Modular Tiny Trailer Home Modular Prefabricated Homes 0

Light Steel Frame Prefab Eco Modular Tiny Trailer Home Modular Prefabricated Homes 1

Light Steel Frame Prefab Eco Modular Tiny Trailer Home Modular Prefabricated Homes 2  Light Steel Frame Prefab Eco Modular Tiny Trailer Home Modular Prefabricated Homes 3



Light Steel Frame Prefab Eco Modular Tiny Trailer Home Modular Prefabricated Homes 4

Applications:
Hotel, House, Office, etc.




Product Description:
DeepBlue earthquake proof prefabricated bungalow is based on a light gauge steel frame system with high-performance finishing materials. The whole house can be assembled within a couple of hours by 4workers.
the materials are the following:
1. Main structure: 89mm light gauge steel framing system based on AS/NZS 4600 standard.
the structure can be design to resist 50m/s wind and 9degree earthquake.
2. Roof structure: 89mm light gauge steel truss system.
3. Chassis: 89mm light gauge steel flooring chassis
4. flooring: 18mm fiber cement board with vapor barrier and bamboo flooring or wooden flooring, Pvc carpet, etc.
5.Wall cladding: 16mm PU insulated steel sandwich panel with beautiful decoration
6. interior lining: 9m fiber cement board, water-proof, termite-proof, security and healthy
7. ceiling: 8mm Pvc ceiling panel
8. insulation: 89mm glass wool insulation with good soundproof performance.
9.windows: PVC sliding windows
10.exterior door: high-quality aluminum sliding windows
11.interior door: painted wood door
12.bathroom: shower, washbasin, toilet included
13. roofing: corrugated steel roofing with the gutter system
14. veranda deck: W.P.C veranda flooring.

Light Steel Frame Prefab Eco Modular Tiny Trailer Home Modular Prefabricated Homes 5
Specifications:
ISO standard steel structure house .one or two also three floors available. fireproof, heat insulation, wind, and earthquake resistance. green, energy-saving. economically.


Why Choose Light Gauge Steel Structure?

1)Lifetime for structure: 100 years.
2)Earthquake resistance: mix more than 8 grades.
3)Wind resistance:max 60m/s.
4)Fire resistance: all the materials used can be fire-resistant.
5)Snow resistance: max 2.9KN/m²as required
6)Heat insulation:100 mm in thickness can match 1 m thickness of the brick wall.
7)High acoustic insulation:60db of exterior wall 40db of interior wall
8)Insect prevention: Free from the damages by insects, such as white ants
9)Ventilation: a combination of natural ventilation or air supply keep the indoor air fresh and clean
10)Packing and delivery: 140SQM/ 40'HQ container for structure only and 90SQM/ 40'HQ container for structure with decorating materials.
11)Installation: the average is one worker one day install one SQM.
12)Installation guide: dispatch engineer to guide on site.

Design code:
(1)AISI S100 North American Specification for the Design of Cold-Formed Steel Structural Members published by the American Iron and Steel Institute (AISI) in the United States.
(2)AS/NZS 4600 Australian/New Zealand Standard-Cold-formed steel structures jointly published by Standards Australia and Standards New Zealand.
(3)BS 5950-5 Structural use of steelwork in building-Part 5. Code of practice for the design of cold-formed thin gauge sections published by BSI in the UK.
(4)ENV1993-1-3 means Eurocode 3: Design of steel structures; Part 1.3: General rules, Supplementary rules for cold-formed thin gauge members.

Light Steel Frame Prefab Eco Modular Tiny Trailer Home Modular Prefabricated Homes 6


Resistant to various weather conditions, due to its light gauge steel framing system, DeepBlue Mobile Homes can resist winds up to 50m/s, 50cm snow loads as well withstand earthquakes due to its special steel structure technology.
The DeepBlue Mobile Houses manufacturing technology is truly a mature product characterized by flexibility and innovative design and solution.

Light Steel Frame Prefab Eco Modular Tiny Trailer Home Modular Prefabricated Homes 7
Light Steel Frame Prefab Eco Modular Tiny Trailer Home Modular Prefabricated Homes 8
Based on our patented foldable technology, transportation and erection can be done in a very simple and convenient way in order to save lots of time, energy, and unnecessary expenses.

Your first choice, Deepblue Prefabrica
