Luxury Prefabricated Garden Office Light Steel Frame With Double Glass Windows

Place of Origin Zhejiang, China (Mainland)
Brand Name Deepblue
Certification ISO9001, CE, AU/NZS
Model Number EH-06
Minimum Order Quantity 4 sets
Price Negotiation
Packaging Details mobile house's packing:well packed export quality package ,shipped by 40hq
Delivery Time 30~45 days
Payment Terms L/C, T/T, Western Union
Supply Ability 120000 Square Meter/Square Meters per Month kit homes

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Use Hotel, House, Kiosk,Booth, Office, Shop, Villa, Workshop,Plant Design Customer Design Avaliable
Color Almost Any Wooden Color Movable Optional
Ceiling Material CFC Board/ Gypsum Board+others Other Fitting Toilet, Washbasin,shower ,kitchen,etc
Insulation Glass Wool/EPS/XPS/PU Sandwich Panel Frame Mterial 0.75mm/0.95mm/1.15mm Steel Frame With AZ150 Zinc Coating
Cladding WPC And Colorbond Windows Double Glass Windows
High Light

steel frame houses

,

modern modular homes

Leave a Message
Product Description

Luxury Prefabricated Garden Office Light Steel Frame With Double Glass Windows



Quick Detail:

Name Garden Studio EH-06 Application holiday living, working studio, yard studio
Color Yellow, white, dark color, etc depend on the customer’s request Feature 1.U.K engineer approved;
2.Earthquake, cyclone and fireproof;
3.100years life;
4.Green, Energy save
Material light steel frame and other parts material Certificate CE,ISO,SAA,ETC



Luxury Prefabricated Garden Office Light Steel Frame With Double Glass Windows 0

Description:

Main structure: Light Gauge Steel Frame
Wall cladding: WPC cladding
Insulation material: Glass wool/ Rock Wool
Ceiling material: PVC/Gypsum board+others
Roof: colorbond
Flooring: laminate flooring/wooden/PVC carpet
Door: steel security door/WPC or wooden door
Window: aluminum alloy/PVC
Other fittings: toilet, washbasin, shower, kitchen, etc.
Lifetime: 100 years for structure


Applications:

the toilet, washbasin, shower, kitchen, study room, etc.


Specifications

No.
Item
Material
Specification
1
Foundation
Fixing to foundation
Chemical bolt
2
Structure
Steel frame wall
0.75/0.95/1.15mm steel wall
Roof truss
0.75/0.95/1.15mm steel truss
Joist (chassis)
0.75/0.95/1.15mm steel joist
3
Roofing system
Batten
35mm batten
Vapor barrier
Normal vapor barrier
Tile
Optional
Insulation
Glasswool
4
Ceiling system
Batten
22mm batten
Ceiling
Gypsum/MGO board, etc.
Insulation
Glasswool
5
Exterior wall
Ext. wall cladding
Optional
Vapor barrier
Normal vapor barrier
Insulation
Glasswool
6
Interior wall
Lining
Optional
Insulation
Glasswool
7
Floor system
Underneath of floor
CFC/ALC board, etc.
Flooring
Optional
Insulation
Glasswool
8
Kitchen
(if in the plan)
Kitchen cabinet
Optional
Countertop
Optional
Sink
Optional
9
Bathroom
(if in the plan)
Toilet
Optional
Washbasin
Optional
Shower
Optional
10
Doors and windows
Exterior door
Optional
Interior door
Optional
Window
Optional



Why Choose Light Gauge Steel Structure?

1)Lifetime for structure: 100 years.
2)Earthquake resistance: mix more than 8 grades.
3)Wind resistance:max 60m/s.
4)Fire resistance: all the materials used can be fire resistant.
5)Snow resistance: max 2.9KN/m²as required
6)Heat insulation:100 mm in thickness can match 1 m thickness of the brick wall.
7)High acoustic insulation:60db of exterior wall 40db of interior wall
8)Insect prevention: Free from the damages by insects, such as white ants
9)Ventilation: a combination of natural ventilation or air supply keep the indoor air fresh and clean
10)Packing and delivery: 140SQM/ 40'HQ container for structure only and 90SQM/ 40'HQ container for structure with decorating materials.
11)Installation: the average is one worker one day install one SQM.
12)Installation guide: dispatch engineer to guide on site.


Design code:

(1)AISI S100 North American Specification for the Design of Cold-Formed Steel Structural Members published by the American Iron and Steel Institute (AISI) in the United States.
(2)AS/NZS 4600 Australian/New Zealand Standard-Cold-formed steel structures jointly published by Standards Australia and Standards New Zealand.
(3)BS 5950-5 Structural use of steelwork in building-Part 5. Code of practice for the design of cold-formed thin gauge sections published by BSI in the UK.
(4)ENV1993-1-3 means Eurocode 3: Design of steel structures; Part 1.3: General rules, Supplementary rules for cold-formed thin gauge members.



Product



Luxury Prefabricated Garden Office Light Steel Frame With Double Glass Windows 1

Luxury Prefabricated Garden Office Light Steel Frame With Double Glass Windows 2



Luxury Prefabricated Garden Office Light Steel Frame With Double Glass Windows 3



Company Introduction



Deepblue Smarthouse was established in the city of NINGBO, CHINA in 2009, thriving and expanding globally being located just 15 minutes from one of the world’s busiest ports - PORT NINGBO. Providing clients with dynamic, superior & cost-effective solutions utilizing light gauge steel frames for housing and commercial projects. Whilst many claims to be professional housing manufacturers, Deepblue never rest, but stand firm with partners and customers delivering turnkey solutions that are code compliant for your country, this commitment to excellence has taught, that the long term knowledge and experience, makes Deepblue the leader in this industry.



Deepblue Smarthouse is focused on providing its client with professional smart housing solutions through products that result in unprecedented customer satisfaction and long-term relationships that allow us as partners, to deliver smart houses for the world!



Luxury Prefabricated Garden Office Light Steel Frame With Double Glass Windows 4

Our Services



If You Need: prefabricated kit home; prefab kit home. steel structure homes.steel frame house, light steel structure, Tiny House on wheels, social house, apartment building, commercial building...



Only Need You To Provide Us: house area, how many floors and bedrooms, luxury or normally, or low-cost configuration.



We Can Provide You: villa; bungalow; low-cost house; granny flat; apartment etc. many style house.
